  2. NanoTune™

Enhanced Splice Experience

NanoTune™ Technology

NanoTune™ enhances your splice experience.
NanoTune™ reduces your time spent working and reduces splicing loss overall,
by using the World’s first※1 AI splicing technology.
※1 Based on an internal investigation.

NanoTune™ Technology
Time-Saving

Features

Time-Saving

Rework, especially of fibre preparation, occasionally need to be done, even with the most skilled workers.
NanoTune™ drastically reduces the need for these reworks, by being able to splice fibres that would have previously required rework.
NanoTune™ realizes this by using state-of-the-art technology and our unique algorithms to accurately adjust parameters when splicing.
NanoTune™ improves your field splice success rate to 90%, thus shortening your working time drastically.

Time-Saving

Success rate increase

75%image90%

Accurate Splicing

Features

Accurate Splicing

Traditional splicers alert and request rework when a bad cleave is detected to maintain good splice performance. If the alert is ignored, bad cleaves often results in bad insertion loss (yellow).
NanoTune™ has improved splicing capabilities of bad cleaves, enabling splicing such fibres with low loss (blue) with the state-of-art AI technology.

Accurate Splicing
  • NanoTune™
  • Conventional machines, spliced with good cleaves
  • Conventional machines, forecefully spliced with bad cleaves

5 Key Technologies

Glass Melting Technology

Key Technology 01

Glass Melting Technology

Mature glass melting techniques,
cultivated as the pioneer in optical fibre manufacturing

Accumulated Knowledge

Key Technology 02

Accumulated Knowledge

Field data collected by the use of SumiCloud™
forms a pool of big data that is used to simulate and analyze potential problems

Cutting Edge AI Technology

Key Technology 03

Cutting Edge AI Technology

State-of-the-art fibre end analysis technology,
with AI based real-time 3D pattern recognition

Optimised Algorithm

Key Technology 04

Optimised Algorithm

Splicing algorithm is optimised to instantly calculate
the best possible splice based on 10 essential splice parameters

Prediction of Core Position

Key Technology 05

Prediction of Core Position

Fibre core position prediction technology,
watching fibres until the moment of splicing

Products

main_image

TYPE-72C+

High Definition
Core Aligning
fusion splicer

For high end
backbone network

Detail

main_image

T-57C+

Core Alignment
fusion splicer

For backbone and
access network

Detail

main_image

T-502S

Active Clad Alignment
fusion splicer

For FTTx network

Detail

main_image

T-402S

Active Clad Alignment
fusion splicer

For FTTx network

Detail

main_image

TYPE-201e-VS

Handheld
fusion splicer

For FTTx network

Detail

main_image

TYPE-201e-M4

Handheld
fusion splicer

For FTTx network

Detail

main_image

TYPE-72M12+

AI-powered ribbon
fusion splicer

For the ribbon cable
network in backbone,
FTTx and data center

Detail

FC-8R

FC-8R

Handheld fibre cleaver

For all cable
construction fields

Detail

FC-6R+

FC-6R+

Benchtop fibre cleaver

For all cable
construction fields

Detail

FC-6C+

FC-6C+

Benchtop fibre cleaver

For all cable
construction fields

Detail

FC-6S+

FC-6S+

Benchtop fibre cleaver

For single fibre bundled
cable construction

Detail

FC-7LS

FC-7LS

Handheld fibre cleaver

For single fibre bundled
cable construction

Detail

About our fusion splicers, fibre cleavers, and other accessories

If you have any questions or inquiries,
please contact our regional sales office.

Contact us
