  3. Lynx-CustomFit™ Field assembly Splice-On Connector

Lynx-CustomFit™ Field assembly
Splice-On Connector

Fusion spliced SC, LC, ST, FC and MPO field
installable fiber optic connectors.

  • Full Lineup

    Full Lineup

  • No Pre-Survey

    No Pre-Survey

  • Perfect Length

    Perfect Length

Lynx-CustomFit™ Field assembly Splice-On Connector
Lynx-CustomFit™ Field assembly Splice-On Connector

What is Lynx-CustomFit™ ?

Field installable connector assembled by Fusion splicer

Field installable connector assembled
by fusion splicer

  • “Factory made” “Japanese quality” ferrule end-face
  • Permanently fusion spliced in connector housing

Featured Products

HDD-LC

Small footprint duplex LC for high density panel

HDD-LC

Duplex LC clip

Retrofittable and detachable

Duplex LC clip

More details

Short Boot

Short boot application optimized for small panels and cabinets

Duplex LC clip

More details

MPO

Ribbon fiber terminating solution for less excess cable management

Bare Ribbon

Bare Ribbon

Ribbon Cord

Ribbon Cord

3mm Round Cord

3mm Round Cord

Solutions

Custom solutions which prove massive efficiencies across stock management, cabling, maintenance, and manufacturing.

Excellent Low Loss

Solution 01

Excellent Low Loss

  • Fusion splice technology directly connects cores

Solution 02

No Pre-Survey

Just prepare Lynx-CustomFit™ connectors and bulk cables, and immediately start!

No Pre-Survey

Solution 03

Perfect Length

  • Slackless cable management
  • Rack space saving

Conventional
Plug & Play Solution

Chaotic routing due to use of
fixed Length pre-terminated cords

Concentional Plug & Play Solution

Lynx-CustomFit™
Solution

Slackless cable management with Lynx-CustomFit™

Lynx-CustomFit™ Solution
Excellent Low Loss

Solution 04

Quick Maintenance (In case of no inventory)

Just prepare Lynx-CustomFit™ connectors
and replace only one connector immediately!

Solution 05

Stock Management

Conventional
Plug & Play Solution

  • Need to have various kinds of SKU
  • Occupy stock yard
Concentional Plug & Play Solution

Lynx-CustomFit™
Solution

  • Just stock Lynx-CustomFit™ connectors and bulk cables
  • Less stock space required
Lynx-CustomFit™ Solution

Solution 06

Manufacturing

Lynx-CustomFit™ Solution

Conventional
Plug & Play Solution

  • Longer production lead time
  • Skilled operators are required
  • Consumables are expensive
Lynx-CustomFit™ Solution

Lynx-CustomFit™
Solution

  • Shorter production lead time
  • Lower initial investment
  • Skilled operators not required

Find Out More Information

Specifications

SC LC FC ST MPO
image image image image image
Interface
Standard
IEC 61754-4 IEC61754-20 IEC 61754-13 IEC 61754-2 IEC 61754-7-1
Fiber Type
and
Polishing Type
SM.APC, SM.UPC
MM50(OM2).PC, MM50(OM3/OM4).PC
MM62.5(OM1).PC
SM.APC
MM50.Flat PC
Insertion Loss
(Against master plug)
SMF: Ave. 0.20dB, Max 0.30dB
MMF: Ave. 0.10dB, Max 0.25dB
SMF (Std Loss): Max 0.75dB
SMF (Low Loss): Max 0.4dB
MMF (Low Loss): Max 0.4dB
Return Loss
(Against master plug)
SMF: ≧60dB(APC), ≧55dB(UPC)
MMF: ≧30dB(PC)
SMF: ≥55dB
Temperature
Conditions
Installation: -5 to 45°C, Operation: -40 to 75°C
Transport: -40 to 50°C, Storage: -40 to 50°C
Qualification IEC 61753-1
GR-326-CORE, GR-1081-CORE
TIA/EIA-568.3-D
GR-1435-CORE
GR-1081-CORE
TIA/EIA-568.3-D

Product Lineup

Lynx-CustomFit™ is designed to meet any application and customer’s needs over 100s types.
Please feel free to contact us if you need any information about Lynx-CustomFit™ .

  • All major connector types available (SC, LC, FC, ST)
  • Covering various fiber type, polishing, cord size
LC SC ST FC Duplex
LC Clip
HDD
LC
MPO
250um fiber / 900um Tight Buffer image image image image image
900um Loose Tube / 900um Loose Buffer image image image image image
250um fiber / 900um Tight Buffer Short Boot image image image
1.6mm / 2mm / 3mm
Jacketed cable
image image image image image 1.6mm and
2mm Only
2mm Loose Tube cable image image image image image
4.8mm Jacketed cable APC
Available
12 fiber / 8 fiber
Bare Ribbon, Ribbon Cord,
3mm Round Cord

Video

Application Area


If you have any questions or inquiries,
please contact our regional sales office.
